NOVA INFINITY ACCESSORY JAW – BOWL JAW SERIES #2

Delivers fast and positive jaw changes which is much faster and less hassle than the screw fastening method with the older NOVA chuck models and other chuck brands. The NOVA Infinity Jaw Key and Infinity Jaws Slides are a precision cast metal amalgam 3x the tensile strength of machine grade steel. Jaw Key positively taper locks into Jaw slide with an embedded dovetail design. A stronger and more rigid bond than the original NOVA Screw on Jaws. The Infinity Jaws are cam locked inline with the forward rotation of the chuck. They are safe to use at higher speeds and larger turning work. The Infinity Jaws are larger, more robust and rigid than the older jaw designs, providing enhanced workholding and turning possibilities. The Infinity Jaws use the well proven NOVA Dovetail Profile, designed to grip the wood firmly for added safety.

The NOVA Infinity Bowl Jaws #2 are capable of holding:
Contracting Grip: Ranges from 31mm/1.22″- 38mm/1.496” (on the NOVA Precision Midi Chuck) through to 31mm/ 1.22″- 65mm/2.56″ (on the NOVA Titan II Chuck)
Expansion Grip: Ranges from 51mm/2.008″- 58mm/2.283″ (on the NOVA Precision Midi Chuck) through to 51mm/ 1.339″- 85mm/3.35″ (on the NOVA Titan II Chuck)
Jaw Spigot Length: 9mm/0.354″

Standard equipment includes:
4 x #2 Infinity Bowl Jaws Segments
Quick Start Instruction Manual
